Dc 12v Digital Display High Temperature Thermometer K Type Thermocouple Industrial Digital Thermometer -20-50 Degrees XH-B310

Overview:
contact
  • Product introduction
  • Technical parameter
  • Product specification
  • Specification model  : XH-B310 Temperature measurement range: -30-800 degreesPower supply voltage :  12V±2VPower supply interface: DC12V±2V Measurement input: K-type thermocouple L=0.5mProbe specification: 304 stainless steel/4*40MM Appearance size: 48*29*23MM Embedded opening: 45.5*26MM Display window: 35*18MM Display color: red, green and blue optional Refresh rate: 500MS/timeResolution: 0.1°C within 100°C/ 1°C outside 100°CReverse connection protection: Yes Own power consumption: <50MA/0.6W Working environment: -20-50 degrees Maximum humidity: 90%-100%/use in non-condensing environment

    Dc 12v Digital Display High Temperature Thermometer K Type Thermocouple Industrial Digital Thermometer -20-50 Degrees XH-B310(图1)

    Dc 12v Digital Display High Temperature Thermometer K Type Thermocouple Industrial Digital Thermometer -20-50 Degrees XH-B310(图2)

    Dc 12v Digital Display High Temperature Thermometer K Type Thermocouple Industrial Digital Thermometer -20-50 Degrees XH-B310(图3)

    Dc 12v Digital Display High Temperature Thermometer K Type Thermocouple Industrial Digital Thermometer -20-50 Degrees XH-B310(图4)

    Dc 12v Digital Display High Temperature Thermometer K Type Thermocouple Industrial Digital Thermometer -20-50 Degrees XH-B310(图5)

    Dc 12v Digital Display High Temperature Thermometer K Type Thermocouple Industrial Digital Thermometer -20-50 Degrees XH-B310(图6)
