Zfx-7016k Temperature Meter Intelligent Temperature Control Switch Thermocouple 999 Degrees Temperature Controller 30a DC24V ZFX

Product model: ZFX-7016K
Temperature control range: 1℃~999℃
Measurement error: ±1℃
Sensor thermocouple 1 meter
Temperature control accuracy: 1℃
Working voltage: 12V/24V/220V
Relay output: 30A/10A optional
Data storage: Yes
Working temperature: 0℃~50℃
Opening size: 70mm*28mm

Panel description

Function description: 1. Press the power button to turn on the thermostat. In the running state, press this button for more than 3 seconds to turn off the thermostat. 2. Long press the S button and the screen will display the setting code, HC, D, LS...AL, etc., press the up and down buttons to find the code that needs to be set. After finding the corresponding code, press the S button once to confirm, and the factory settings will appear. After pressing the up and down keys to adjust the temperature value you need, wait for three seconds to automatically save and exit

Product wiring

Internal display
